How to Perform Oil Analysis
Oil analysis provides a look inside your engine to gauge oil and component condition.
Article based ‘the INSIDE TRACK’ Amsoil Blog on April 25, 2023 Amsoil Blog by David Hilgendorf | Amsoil Technical Writer links added by National Synthetics staff
Used oil analysis is one of the most potent tools in your maintenance arsenal. It provides a simple, inexpensive and accurate glimpse inside your engine or equipment to help gauge lubricant and component condition, without removing a bolt or bloodying a knuckle. Here’s how to perform oil analysis.
What is oil analysis?
Oil analysis is the process of chemically analyzing a lubricant sample to determine the condition of the lubricant itself as well as the engine or other lubricated components it interacts with.
To have your oil analyzed, you must take a sample of the lubricant and ship it to a qualified laboratory. Technicians subject the lubricant to a range of tests to determine the concentration of wear metals, fuel dilution, the lubricant’s total base number (TBN), oxidation and other information. The lab will return a report on the lubricant’s condition and includes a brief explanation and recommendations for future service.
Benefits of oil analysis
Determining the condition of the oil inside your engine offers several benefits, all of which can save you time, money and hassle in the future.
- Maximize oil life
Monitoring the condition of the oil allows you to optimize drain intervals, so you can maximize the fluid’s service life. Performing fewer oil changes minimizes maintenance costs and reduces downtime for businesses that depend on equipment and vehicle availability. It also reduces the amount of waste oil, which helps the environment.
- Prevent equipment failure
Oil analysis identifies dirt, wear particles, fuel dilution, coolant and other contaminants that can cause catastrophic failure or significantly shorten equipment life, allowing you to proactively fix problems before they happen.
- Increase resale value
Oil analysis creates documentation of the equipment’s history and performance, which helps it maintain its value.
How to perform oil analysis
It is easy to perform oil analysis by obtaining an oil analysis kit from Oil Analyzers Inc. For this example, we used a 1998 Toyota* Corolla.* This vehicle was also used to demonstrate testing engine compression. Here’s what you’ll need to perform oil analysis:
- Oil analysis kit
- Sampling pump with hose
Warm up the engine
Warm oil flows more easily through the sampling pump and circulating the oil prior to drawing a sample ensures consistency. Run the vehicle for a couple of minutes; there’s no need to reach operating temperature.
Draw the oil sample
Using a vacuum pump is the easiest and cleanest way to accomplish this, allowing access to the oil sump through the dipstick tube. Thread the clean sample bottle included in the testing kit to the pump. Attach a clean hose (the length of the dipstick plus one foot) to the top of the pump and tighten the lock ring.
PRO TIP: Trim the end of the sampling hose at a 45-degree angle to make insertion easier.
Insert the hose into the dipstick tube until it bottoms out in the oil sump, then retract the tube about an inch, so it won’t pull contaminants off the bottom of the oil pan. Pump the plunger until the bottle is 3/4 full.
Sometimes it’s impossible to draw an oil sample from the top, so you’ll have to pull the sample straight from the drain hole, which is messier. Simply allow the lubricant to drain for a few seconds so contaminants that have settled around the drain plug are flushed out before catching a sample directly in the bottle. Quickly reinstall the drain plug and top-off the reservoir.
Ship the oil sample
Most oil analysis kits come with the appropriate labels and directions for shipping it to a lab. Follow the instructions, then sit tight until the results arrive.
Read the results
Oil Analyzers Inc. typically returns results either by email or via an online portal about two business days after receiving the sample. The lab report includes application information, elemental analysis and recommendations. The amount of information varies depending on the test kit you choose.
Reading an oil analysis report
Here’s the report for a 1998 Corolla* with 11,000 miles and 11 months on the oil. Note the severity status level in the upper right, which provides a quick reference to determine the status of the sample.
- Severity 0 (Normal) = Oil is suitable for continued use.
- Severity 1 (Normal) = Oil is suitable for continued use. Observe trends in future tests.
- Severity 2 (Abnormal) = Oil is suitable for continued use. Resample at half the normal interval.
- Severity 3 (Abnormal) = Replace oil filter and top-off system with fresh oil. Resample at half the normal interval or change oil.
- Severity 4 (Critical) = Change oil and filter if not done when sample was taken.
This sample fell into the Severity 2 category. Note the Multi-Source Metals and Additive Metals are highlighted in yellow.
The Comments section explains: “Flagged additive levels are lower than expected for the identified lubricant. This may have been topped off with a different lubricant, the fluid may be misidentified, or a different lubricant or formulation may have been in use prior to a recent change.”
The oil was, in fact, topped-off with a different AMSOIL product than the Signature Series 0W-30 Synthetic Motor Oil installed 11 months earlier. While mixing lubricants won’t harm the engine, this report shows how it disrupts the oil’s chemistry, which can shorten its service life and reduce performance.
Overall results were good for an older car with more than 150,000 miles and an unknown motor oil history. Wear metals were low, meaning the oil was doing an excellent job protecting the bearings and other components from wear. Contaminants were also low, meaning the filter was capturing debris before it reached the engine. There’s no glycol contamination, which means the engine coolant was not leaking into the oil. And oil viscosity and oxidation were both good, indicating the oil was holding up, even after 11 months.
The only areas to watch were a “moderate” 3% fuel dilution and moderately low TBN, neither of which was at a level necessitating changing the oil.
This is a perfect example of the power of oil analysis, as it identified fuel-dilution and allows monitoring for more problematic levels in future testing. The knowledge that this engine suffers moderate fuel dilution also reinforces the importance of using a high-quality synthetic oil to ensure maximum protection.
Oil analysis is relatively inexpensive for the information it provides. It empowers you to take better care of your vehicles and equipment to reduce downtime and maintenance costs and maximize the return on your investment.
*All trademarked names and images are the property of their respective owners and may be registered marks in some countries. No affiliation or endorsement claim, express or implied, is made by their use.
